Weld Procedure Qualification Records
Flux Cored Arc Welding
| Document PQR |
Joint |
Material 1 |
Material 2 |
Consumable's |
Thickness
Range mm |
Pos |
Standard |
| FCAW-01 |
Fillet |
ASTM A240-A480 |
ASTM A240-A480 |
Lincoln FC-316L |
37 to 75 |
3F |
AS1210 ASME IX |
| FCAW-02 |
Butt |
UNS - N08904 (K) |
UNS - N08904 (K) |
SWP-Tetra V 904 LG / E358LTI-1 |
5 to 24 |
1G |
AS3992:1998 |
| FCAW-03 |
Butt |
A1 / ASTM SA106B |
A1 / ASTM SA106B |
Outershield E712C |
5 to 21.94 |
6G |
AS3992 ASME IX |
| FCAW-04 |
Butt |
AS3678/300 |
AS3678/300 |
Outershield E712C |
5 to 20 |
3G |
AS1554.5 |
| FCAW-05 |
Butt |
ASTM SA106B (A1) |
ASTM SA106B (A1) |
ESAB Coreshield 8 |
5 to 21.94 |
6G |
AS3992 ASME IX |
| FCAW-06 |
Butt |
AS 3678-300 (A1) |
AS 3678-300 (A1) |
Innershield 233 |
6 to 24 |
3G |
AS3992 |
| FCAW-07 |
Butt |
AS 3678-300 (A1) |
AS 3678-300 (A1) |
Innershield 233 |
6 to 24 |
2G |
AS3992 |
| FCAW-08 |
Butt |
ASTM A106B (A1) |
ASTM A106B (A1) |
Lincoln Innershield 212 |
5.5 to 22 |
6G |
AS3992 ASME IX |
| FCAW-09 |
Fillet |
ASTM A276-98B |
ASTM A276-98B |
ER2209 Tetra V 229 3L-G |
2.5-10 |
2F |
AS1554-6ASME IX |
| FCAW-10A |
Butt |
ASTM A106B / AS 1163-C350LO (5) |
ASTM A106B / AS 1163-C350LO (5) |
E71T-1 (1.2 mm) |
12.7 |
6G |
AS1554.1 2004 |
| FCAW-10B |
Butt |
ASTM A106B (A1) |
ASTM A106B (A1) |
E71T-1 (1.2 mm) |
12.7 |
6G |
AS3992:1998 CLASS 1 |
| FCAW-11A |
Fillet |
AS3678-300 (A1) |
AS3678-300 (A1) |
E71T-8-H8 (Lincoln Innershield 233) |
6 to 24 |
4F |
AS1554.1 2011 |
| FCAW-11B |
Butt |
AS3678-250 (A1) |
AS3678-250 (A1) |
E71T-8-H8 (Lincoln Innershield 233) |
10 to 40 |
4F |
AS1554.1 2011 |
| FCAW-12A |
Butt |
UNS 532750 (P-10H) |
UNS 532750 (P-10H) |
E2594T1-4 (Supercore 2507P) |
5.4 to 21.39 |
6G |
AS3992:1998 AS4037:1999 CL 1 |
| FCAW-12B |
Butt |
UNS 532750 (P-10H) |
UNS 532750 (P-10H) |
E2594T1-4 (Supercore 2507P) |
5.4 to 21.39 |
6G |
ASME IX:2010 |
| FCAW-13A |
Butt |
ASTM SA106B (A1) |
ASTM SA106B (A1) |
E71T-1 (ESAB 7100 Ultra) |
11 to 44 |
6G |
AS1554.1 2011 |
| FCAW-13B |
Butt |
ASTM SA106B (A1) |
ASTM SA106B (A1) |
E71T-1 (ESAB 7100 Ultra) |
5 to 44 |
6G |
AS3992:1998 |
| FCAW-13C |
Butt |
ASTM SA106B (A1) |
ASTM SA106B (A1) |
E71T-1 (ESAB 7100 Ultra) |
11 to 44 |
6G |
ASME IX:2010 |
| FCAW-14A |
Butt |
AS 3678-350 (A1) |
AS 3678-350 (A1) |
E71T-1 (ESAB 7100 Ultra) |
5 to 50 |
1G |
AS3992:1998 |
| FCAW-14B |
Butt |
AS 3678-350 (A1) |
AS 3678-350 (A1) |
E71T-1 (ESAB 7100 Ultra) |
2.5 to 50 |
1G |
AS1554.1:2011 SP |
| FCAW-14C |
Fillet |
AS 3678-350 (A1) |
AS 3597- Bisalloy 360 (A3) |
E71T-1 (ESAB 7100 Ultra) |
10 to 70 |
2F |
AS1554.1:2011 SP |
| FCAW-15 |
Fillet |
AS 4671-500N |
AS 4671-500N |
E71T-8-D (1.2mm) |
20 Dia |
3F |
AS1554.3:2008 |
| FCAW-16A |
Butt |
AS 3678-350 (A1) |
AS 3678-350 (A1) |
E71T-1 (ESAB 7100 Ultra) |
12.5 to 50 |
3G |
AS1554.1:2011 SP |
| FCAW-16B |
Butt |
AS 3678-350 (A1) |
AS 3678-350 (A1) |
E71T-1 (ESAB 7100 Ultra) |
12.5 to 50 |
3G |
AS3992:1998 |
| FCAW-17 |
Fillet |
ASTM A240-A480 Grade 316 (K) |
AS 3678-350 (A1) |
E309LT1-1/-4 (Lincoln FCP-309L) |
6 to 40 |
3F |
AS3992:1998 AS4041:2006 CL2 |
| FCAW-18 |
Fillet |
AS 3678-350 LO(A1) |
AS 3678-350 LO(A1) |
E71T-11 (Innershield NR211) |
3 to 20 |
5F |
AS1554.1:2011 SP |
| FCAW-19 (PQ) |
Fillet |
AS 3678-350 LO(A1) |
AS 3678-350 (A1) |
E71T-1 (ESAB 7100 Ultra) |
ALL |
2F |
AS1554.1:2011 SP |
| FCAW-20 (PQ) |
Fillet |
AS 3678-350 LO(A1) |
AS 3678-350 (A1) |
E71T-1 (ESAB 7100 Ultra) |
ALL |
3F |
AS1554.1:2011 SP |
| FCAW-21 (PQ) |
Fillet |
AS 3678-350 LO(A1) |
AS 3678-350 (A1) |
E71T-1 (ESAB 7100 Ultra) |
ALL |
3F |
AS1554.1:2011 SP |
| FCAW-22 (PQ) |
Fillet |
AS 3678-350 LO(A1) |
AS 3678-350 (A1) |
E71T-1 (ESAB 7100 Ultra) |
ALL |
2F |
AS1554.1:2011 SP |
| FCAW-23 |
Butt |
AS 3678-350 (A1) |
AS 3678-350 (A1) |
E71T-1 (ESAB 7100 Ultra) |
5 to 32 |
3G |
AS1554.1:2014 SP |
| FCAW-24 |
Fillet |
ASTM A240/316L |
ASTM A240/316L |
E316T1/T1-4 (1.2mm Flux) |
6 |
3F |
AS1554.6:2012 |
| FCAW-25 |
Butt |
ASTM SA106B/AS1163-C350LO |
ASTM SA106B/AS1163-C350LO |
E71T-1 (1.2mm) |
10.97 |
6G |
AS1554.1 SP:2014 |
| FCAW-26 |
Fillet |
UNS S32750/2507 Super Duplex |
UNS S32750/2507 Super Duplex |
A5.22:E2594T1-1 (1.2mm) |
6 |
2F |
AS1554.6:2012 |
| FCAW-27 |
Fillet |
AS 4671-500 (RE-BAR) |
AS 4671-500 (RE-BAR) |
E71T-8JD H8 |
28 Dia |
2F |
AS1554.3:2014 |
| FCAW-28 |
Fillet |
Bisalloy 400 |
AS 3678-350 (A1) |
E71T-T5 |
8 |
2F |
AS1554.1 SP:2014 |
| FCAW-29 |
Butt |
Bisalloy 400 |
AS 3678-350 (A1) |
E71T-T5 |
12 |
1G |
AS1554.1 SP:2014 |
Gas Metal Arc Welding
| Document PQR |
Joint |
Material 1 |
Material 2 |
Consumable's |
Thickness
Range mm |
Pos |
Standard |
| GMAW-01 |
Butt |
A1 / ASTM SA106B |
A1 / ASTM SA106B |
Autocraft LW1 |
9.53 to 21.94 |
6G |
AS3992 ASME IX |
| GMAW-02 |
Butt |
ASTM A240 - 304L (K) |
ASTM A240 - 304L (K) |
ER 308L Si |
1.5 to 12 |
1G |
AS3992 ASME IX |
| GMAW-03 |
Butt |
ASTM A312 - 316 (K) |
ASTM A312 - 316 (K) |
BOC 316L Si |
1.5 to 24 |
2G |
AS3992 AS4041 |
| GMAW-04 |
Butt |
UNS S30400 |
UNS S30400 |
ER 308L Si |
5 to 22 |
6G |
AS3992 ASME IX |
| GMAW-05 |
Butt |
UNS S31603 (P8) |
UNS S31603 (P8) |
ES 316 LSi |
1.5 to 15 |
6G |
AS3992 ASME IX |
| GMAW-06A |
Fillet |
ASTM A240-316L |
AS 3679.1-300 |
BOC ER309L Si |
ALL |
2F |
AS3992, ASME IX |
| GMAW-07 |
Butt |
ASTM A240-340L |
AS 3678 GRADE 350 |
BOC 309LSi |
15 to 45 |
1G |
AS1554.6 |
| GMAW-08 |
Fillet |
AS 1163-C450LO (7B) |
AS 1163-C450LO (7B) |
E70C-6M 4 (Metal Core) (1.2mm) |
10 |
2F |
AS 1554.1 SP:2014 |
| GMAW-09 |
Fillet |
UNS S32750/2507 Super Duplex |
UNS S32750/2507 Super Duplex |
A5.9:ER2594 (1.2mm) |
6 |
2F |
AS1554.6:2012 |
| GMAW-10 |
Fillet |
ASTM A240-253MA |
ASTM A240-253MA |
Sanvik 22.12.HT |
3 to 24 |
2F |
AS1554.6:2012 |
| GMAW-11 |
Butt |
ASTM SA106B (A1) |
ASTM SA106B (A1) |
E70C-6M 4 (Metal Core) (1.2mm) |
1G |
5 TO 25.4 |
AS3992, ASME 1X, AS1554 |
| GMAW-12 |
Fillet |
AS 1163-C450LO (7B) |
AS 1163-C450LO (7B) |
ER 70S-6 (.9mm) |
6 |
2F |
AS 1554.1 SP:2014 |
| GMAW-13 |
Butt |
AS 1163-C450LO (7B) |
AS 1163-C450LO (7B) |
ER 70S-6 (.9mm) |
9 |
2G |
AS 1554.1 SP:2014 |
| GMAW-14 |
Butt |
AS 1163-C450LO (7B) |
AS 1163-C450LO (7B) |
ER 70S-6 (.9mm) |
9 |
2G |
AS 1554.1 SP:2014 |
| GMAW-15 |
Fillet |
AS 1163-C450LO (7B) |
AS 1163-C450LO (7B) |
ER 70S-6 (.9mm) |
8 |
2F |
AS 1554.1 SP:2014 |
| GMAW-16 |
Plug |
AS 1163-C450LO (7B) |
AS 1163-C450LO (7B) |
ER 70S-6 (.9mm) |
9 |
1F |
AS 1554.1 SP:2014 |
| GMAW-17 |
Fillet |
UNS S32205 Duplex |
UNS S32205 Duplex |
ER 2209 (.9mm) |
6 |
2F |
AS 1554.6:2012 CL B |
| GMAW-18 |
Butt |
UNS S32205 Duplex |
UNS S32205 Duplex |
ER 2209 (.9mm) |
8 |
1G |
AS 1554.6:2012 CL B |
| GMAW-19 |
Butt |
ASTM SA106B (5) |
ASTM SA106B (5) |
E70S-6 (1.2mm) |
12.7 |
6G |
AS1554.1 SP:2014 |
| GMAW-FCAW-01 |
Butt |
ASTM A240 53B |
ASTM A240 53B |
Autocraft LW1/ SMOOTHCOR 711 |
2.7-10.9 |
6G |
AS3992 ASME IX |
| GMAW-FCAW-02 |
Butt |
ASTM 316L |
ASTM 316L |
BOC 316LSi |
3 to 13 |
3G |
AS4041, ASMEIX |
| GMAW-FCAW-03 |
Butt |
AS 3678-350 (A1) |
AS 3678-350 (A1) |
ES704S (LW1) E71T-1 (ESAB 7100 Ultra) |
5 TO 32 |
1G |
AS1554.1:2014 |
| GMAW-FCAW-04 |
Butt |
AS 1163-C450LO (7B) |
AS 1163-C450LO (7B) |
ER 70S-6 (.9mm / E71T-1 (1.2mm) |
9 |
2G |
AS 1554.1 SP:2014 |
| GMAW-FCAW-05 |
Butt |
AS 1163-C450LO (7B) |
AS 1163-C450LO (7B) |
ER 70S-6 (.9mm / E71T-1 (1.2mm) |
9 |
3G |
AS 1554.1 SP:2014 |
| GMAW-FCAW-06 |
Butt |
AS 1163-C450LO (7B) |
AS 1163-C450LO (7B) |
ER 70S-6 (.9mm / E71T-1 (1.2mm) |
9 |
2G |
AS 1554.1 SP:2014 |
| GMAW-SAW-01 |
Butt |
AS 3678-350 (4) |
AS 3678-350 (4) |
E70C-6M 4 / ISO 14171-B SU21 |
5-20 |
1G |
AS 1554.1 SP:2014 |
Gas Tungsten Arc Welding
| Document PQR |
Joint |
Material 1 |
Material 2 |
Consumable's |
Thickness
Range mm |
Pos |
Standard |
| GTAW-01 |
Butt |
A1 / ASTM SA106B |
A1 / ASTM SA106B |
Autocraft LW1 |
1.58 to 11.08 |
6G |
AS3992 ASME IX |
| GTAW-02 |
Butt |
UNS - N08904 (K) |
UNS - N08904 (K) |
Metrode 20-25-4 |
1.5 to 8.4 |
6G |
AS3992 ASME IX |
| GTAW-03 |
Butt |
ASTM A312 - 304L (K) |
ASTM A312 - 304L (K) |
Metrode 20-25-4 |
1.5 to 8.4 |
6G |
AS3992 ASME IX |
| GTAW-04 |
Butt |
ASTM A312 - 316 (K) |
ASTM A312 - 316 (K) |
BOC Profill 316L / ER316L |
1.5 to 15.24 |
6G |
AS3992 ASME IX |
| GTAW-05 |
Butt |
ASTM A312 - 316 (K) |
ASTM A312 - 316 (K) |
BOC Profill 316L / ER316L |
1.5 to 12 |
2G |
AS4037:2001 |
| GTAW-06 |
Butt |
ASTM A312 - 316 (K) |
A1 / ASTM SA106B |
BOC Profill 309L / ER309L |
1.5 to 11.08 |
6G |
AS3992 ASME IX |
| GTAW-07 |
Butt |
ASTM A312 - 316 (K) |
ASTM A312 - 316 (K) |
Kobelco TGX and BOC Profill 316L |
1.5 to 8.38 |
6G |
AS3992 ASME IX |
| GTAW-08 |
Butt |
UNS N10276 |
UNS N10276 |
Techalloy C-276 |
1.5 to 7.36 |
6G |
AS3992 ASME IX |
| GTAW-09 |
Fillet |
ASTM A276.98B |
ASTM A276.98B |
ER2209 Sandvik 2209 |
2.5-10 |
2F |
AS1554-6 ASME IX |
| GTAW-08 |
Butt |
UNS N10276 |
UNS N10276 |
Techalloy C-276 |
1.5 to 7.36 |
6G |
AS3992 ASME IX |
| GTAW-09 |
Butt |
UNS S32750/2507 Super Duplex |
UNS S32750/2507 Super Duplex |
A5.9/ER2594 (2.4mm) |
3 |
6G |
AS1554.6:2012 |
| GTAW-10 |
Butt |
UNS S32750/2507 Super Duplex |
UNS S32750/2507 Super Duplex |
A5.9/ER2594 (2.4mm) |
3 |
6G |
AS3992 ASME IX |
| GTAW-FCAW-01 |
Butt |
ASTM A240-316L |
ASTM A240-316L |
Metrode 20-25-4 / SWP Tetra V904 |
1.5 to 12 |
1G |
AS3992 ASME IX |
| GTAW-FCAW-02 |
Butt |
ASTM 106B |
ASTM 106B |
Autocraft LW1 / Smooth-Cor711 |
5 to 22 |
6G |
AS3992 ASME IX |
| GTAW-FCAW-03 |
Butt |
ASTM A276-98B |
ASTM A276-98B |
ER2209/ER2209T1-4 |
3 to12 |
1G |
AS3992 ASME IX |
| GTAW-GMAW-02 |
Butt |
ASTM A240-253MA |
ASTM A240-253MA |
Sanvik 22.12.HT |
12 |
2G |
AS1554.6:2012 |
| GTAW-MMAW-01 |
Butt |
ASTM A240-316L |
ASTM A240-316L |
Metrode 20-25-4/Metrode 21-26-5 |
1.5 to 12 |
1G |
AS3992 ASME IX |
Manual Metal Arc Welding
| Document PQR |
Joint |
Material 1 |
Material 2 |
Consumable's |
Thickness
Range mm |
Pos |
Standard |
| MMAW-01 |
Butt |
ASTM A240-316L |
ASTM A240-316L |
Metrode 21-26-5 |
1.5 to 12 |
1G |
AS3992 ASME IX |
| MMAW-02 |
Butt |
UNS - N08904 (K) |
UNS - N08904 (K) |
Metrode 21-26-5 |
1.5 to 12 |
1G |
AS3992 ASME IX |
| MMAW-03 |
Butt |
A1 / ASTM A106B |
A1 / ASTM A106B |
Kobe LB52U / E7016 |
5 to 22 |
6G |
AS3992 ASME IX |
| MMAW-04 |
Fillet |
ASTM A240-316L |
AS3678-300 |
EN1600-97E23 / AWS A5.4 309L |
1.5 to 16 |
2F |
AS3992 ASME IX |
| MMAW-05 |
Fillet |
AS3678/250 |
AS3678/250 |
Smootharc 24 / ASME/SFA E7024 |
3 to 12 |
2F |
AS1554.1 |
| MMAW-06 |
Fillet |
ASTM A276.98B |
ASTM A276.98B |
E2209-17 Sandvik 22.9.3LR |
2.5-10 |
2F |
AS1554-6 ASME IX |
| MMAW-07 |
Butt |
ASTM A106 Gr.B |
ASTM A106 Gr.B |
E4916 |
11-44 |
6G |
AS/NZS3992 AS1554 ASME IX |
| MMAW-08 |
Butt |
ASTMA 106 Gr.B |
ASTMA 106 Gr.B |
E4110/E7018 |
3.5-14 |
6G |
AS/NZS3992 AS1554 ASME IX |
| MMAW-12 |
Fillet |
AS/NZS 3679.1-300 |
AS2074H1A (Austenitic Manganese Steel) |
309L |
12 to 19 |
4F |
AS1554.6-2012 cat 1B |
| MMAW-13 |
Fillet |
AS 4671-500N |
AS 4671-500N |
E71T-8-D (1.2mm) |
20 Dia |
3F |
AS1554.3:2008 |
| MMAW-FCAW-01 |
Butt |
ASTM A240 - 316 L |
ASTM A240 - 316 L |
Metrode 21-26-5 / SWP Tetra V904 |
1.5 to 12 |
1G |
AS3992 ASME IX |
| MMAW-FCAW-02 |
Butt |
ASTM A106B (A1) |
ASTM A106B (A1) |
Lincoln 5P |
5.5 to 22 |
6G |
AS3992 ASME IX |
Submerged Arc Welding
| Document PQR |
Joint |
Material 1 |
Material 2 |
Consumable's |
Thickness
Range mm |
Pos |
Standard |
| SAW-01 |
Butt |
AS3678/300 |
AS3678/300 |
Lincoln L60 |
10 to 25 |
1G |
AS1554.5 |
| SAW-02 |
Butt |
AS 3679-300 |
AS 3679-300 |
Lincoln L60 |
5 to 20 |
1G |
AS1554.5 |
Resistance Fusion Welding (Stud Welding)
| Document PQR |
Joint |
Material 1 |
Material 2 |
Consumable's |
Thickness
Range mm |
Pos |
Standard |
| STAW-01 |
Fillet |
AS 1548 7-460R |
AS 1443 - Gr. M1020 (STUD) |
Ø22 STUD |
22 |
1G |
AS1554.2 |
| STAW-02 |
Fillet |
AS 3678-250 |
AS 1443 - Gr. M1020 (STUD) |
Ø16 STUD |
16 |
1G |
AS1554.2 |
Weld Procedure Specifications
Flux Cored Arc Welding
| Document WPS |
Joint |
Material 1 |
Material 2 |
Consumable's |
Pos |
Standard |
| FCAW-01-01 |
Fillet |
ASTM A240-A480 |
ASTM A240-A480 |
Lincoln FC-316L |
3F |
AS1210, ASME IX:2004 |
| FCAW-03-01 |
Butt |
A1 / ASTM SA106B |
A1 / ASTM SA106B |
Outershield E712C |
1G |
AS3992:1998, ASME IX:2004 |
| FCW-03-02 |
Fillet |
A1 / ASTM SA106B |
A1 / ASTM SA106B |
Outershield E712C |
2F |
AS3992:1998, ASME IX:2004 |
| FCAW-03-03 |
Fillet |
A1 / ASTM SA106B |
A1 / ASTM SA106B |
Outershield E712C |
3F |
AS3992:1998, ASME IX:2004 |
| FCAW-03-04 |
Butt |
A1 / ASTM SA106B |
A1 / ASTM SA106B |
Outershield E712C |
2G |
AS3992:1998, ASME IX:2004 |
| FCAW-03-05 |
Butt |
A1 / ASTM SA106B |
A1 / ASTM SA106B |
Outershield E712C |
3G |
AS3992:1998, ASME IX:2004 |
| FCAW-03-06 |
Butt |
A1 / ASTM A106B |
A1 / ASTM A106B |
Outershield E712C |
3G |
AS3992:1998, ASME IX:2004 |
| FCAW-06-01 |
Butt |
AS 3678-300 (A1) |
AS 3678-300 (A1) |
Innershield 233 |
3G |
AS3992:1998, ASME IX |
| FCAW-06-02 |
Fillet |
AS 3678-300 (A1) |
AS 3678-300 (A1) |
Innershield 233 |
1F |
AS3992:1998, ASME IX |
| FCAW-08-01 |
Butt |
ASTM SA106B (A1) |
ASTM SA106B (A1) |
Lincoln Innershield 212 |
3G |
AS3992:1998, ASME IX |
| FCAW-08-02 |
Butt |
ASTM SA106B (A1) |
ASTM SA106B (A1) |
Lincoln Innershield 212 |
2G |
AS3992:1998, ASME IX |
| FCAW-08-03 |
Fillet |
AS3678-300 (A1) |
AS3678-300 (A1) |
Lincoln Innershield 212 |
3F |
AS3992:1998, ASME IX |
| FCAW-08-04 |
Fillet |
AS3678-300 (A1) |
AS3678-300 (A1) |
Lincoln Innershield 212 |
4F |
AS3992:1998, ASME IX |
| FCAW-08-05 |
Butt |
AS3678-300 (A1) |
AS3678-300 (A1) |
Lincoln Innershield 212 |
5F |
AS3992:1998, ASME IX |
| FCAW-08-06 |
Butt |
ASTM SA106B (A1) |
ASTM SA106B (A1) |
Lincoln Innershield 212 |
1G + 4G |
AS3992:1998, ASME IX |
| FCAW-08-07 |
Butt |
ASTM SA106B (A1) |
ASTM SA106B (A1) |
Lincoln Innershield 212 |
3G |
AS3992:1998, ASME IX |
| FCAW-08-08 |
Butt |
ASTM SA106B (A1) |
ASTM SA106B (A1) |
Lincoln Innershield 212 |
4G |
AS3992:1998, ASME IX |
| FCAW-08-09 |
Butt |
ASTM SA106B (A1) |
ASTM SA106B (A1) |
Lincoln Innershield 212 |
1G + 4G |
AS3992:1998, ASME IX |
| FCAW-08-10 |
Fillet |
AS3678-300 (A1) |
AS3678-300 (A1) |
Lincoln Innershield 212 |
2F |
AS3992:1998, ASME IX |
| FCAW-09-01 |
Fillet |
ASTM A276-98B |
ASTM A276-98B |
E2209T1-4 Tetra V 229-3L-G |
2F |
AS1554-6 ASME IX |
| FCAW-10-01 |
Butt |
ASME B36.10M |
ASME B36.10M |
E71 T1 ETPGCpW503A.CM1.H10 |
2G |
AS1554.1 :2004 |
| FCAW-10-02 |
Butt |
ASME B36.10M |
ASME B36.10M |
E71 T1 ETPGCpW503A.CM1.H10 |
3G |
AS1554.1 :2004 |
| FCAW-11-01 |
Fillet |
AS3678-300 (A1) |
AS3678-300 (A1) |
E71 T1 ETP-GCp-W503A.CM1.H10 |
4F |
AS1554.1 :2011 |
| FCAW-PR-01 |
Butt |
AS3678 GR.250 (A1) |
AS3678 GR.250 (A1) |
CIGWELD SUPRE-COR 5 |
4G |
AS1554.1:2000 |
Gas Metal Arc Welding
| Document WPS |
Joint |
Material 1 |
Material 2 |
Consumable's |
Pos |
Standard |
| GMAW-01-01 |
Fillet |
AS1548-7-460R (A1) |
AS1548-7-460R (A1) |
Autocraft LW1 |
2F |
AS3992:1998, ASME IX:2004 |
| GMAW-01-02 |
Butt |
AS1548-7-460R (A1) |
AS1548-7-460R (A1) |
Autocraft LW1 |
6G |
AS3992:1998, ASME IX:2004 |
| GMAW-01-03 |
Butt |
AS1548-7-460R (A1) |
AS1548-7-460R (A1) |
Autocraft LW1 |
6G |
AS3992:1998, ASME IX:2004 |
| GMAW-01-04 |
Fillet |
AS3678 GR250 (A1) |
AS3678 GR250 (A1) |
Autocraft LW1 |
2F |
AS3992:1998, ASME IX:2004 |
| GMAW-01-05 |
Fillet |
AS3678 GR250 (A1) |
AS3678 GR250 (A1) |
Autocraft LW1 |
3F |
AS3992:1998, ASME IX:2004 |
| GMAW-01-06 |
Fillet |
A1 / ASTM SA106B |
A1 / ASTM SA106B |
Autocraft LW1 |
2F |
AS3992:1998, ASME IX:2004 |
| GMAW-02-01 |
Fillet |
ASTM A240-304L |
AS3678 GR250 (A1) |
Autocraft 309L Si |
1G |
AS3992:1998, ASME IX:2004 |
| GMAW-02-02 |
Fillet |
ASTM A240 - 304L (K) |
AS3678 GR.250 (A1) |
AUTOCRAFT 309LSi |
2F |
AS 3992:1998, ASME IX |
| GMAW-04-01 |
Fillet |
UNS S3044 |
UNS S30400 |
Lincoln 308LSi |
2F |
AS 3992:1998, ASME IX |
| GMAW-04-02 |
Butt |
UNS S3044 |
UNS S30400 |
BOC 308 LSI |
1G |
AS3992:1998, ASME IX:2004 |
| GMAW-05-01 |
Butt |
ASTM A276 (P8) |
ASTM A276 (P8) |
BOC 316LSi |
2G |
AS3992 ASME IX |
| GMAW-05-02 |
Butt |
ASTM A276 (P8) |
ASTM A276 (P8) |
BOC 316LSi |
3G |
AS3992 ASME IX |
| GMAW-PR-01 |
Butt |
AS3678 GR250 (A1) |
AS3678 GR250 (A1) |
Autocraft LW1 |
1G |
AS1554:2000 |
| GMAW-PR-02 |
Fillet |
AS3678 GR250 (A1) |
AS3678 GR250 (A1) |
Autocraft LW1 |
1F |
AS1554:2000 |
| GMAW-06A-01 |
Fillet |
ASTM A240 - 316L |
AS3679.1 GR300 |
BOC ER309 LSI |
2F |
AS3992:1998, ASME IX:2004 |
Gas Tungsten Arc Welding
| Document WPS |
Joint |
Material 1 |
Material 2 |
Consumable's |
Pos |
Standard |
| GTAW-01-01 |
Butt |
ASTM SA106B (A1) |
ASTM SA106B (A1) |
Comweld LW1 |
2G |
AS3992:1998, ASME IX |
| GTAW-01-02 |
Butt |
ASTM SA106B (A1) |
ASTM SA106B (A1) |
Comweld LW1 |
3G |
AS3992:1998, ASME IX |
| GTAW-01-02A |
Fillet |
ASTM A106B (A1) |
ASTM A106B (A1) |
Comweld LW1 |
5F |
AS3992:1998, ASME IX |
| GTAW-01-03 |
Fillet |
ASTM A106B (A1) |
ASTM A106B (A1) |
Comweld LW1 |
2F |
AS3992:1998, ASME IX |
| GTAW-01-04 |
B/F |
ASTM A106B (A1) |
ASTM A106B (A1) |
Comweld LW1 |
6G + 5F |
AS3992:1998, ASME IX |
| GTAW-02-01 |
Fillet |
UNS N08904 (K) |
UNS N08904 (K) |
Metrode 20.25.4Cu |
5F |
AS3992:1998, ASME IX |
| GTAW-03-01 |
Fillet |
ASTM A312-304L (K) |
ASTM A312-304L (K) |
Metrode 20.25.4 / ER385 |
6G |
AS3992:1998, ASME IX:2004 |
| GTAW-03-02 |
Butt |
ASTM A312-316L (K) |
ASTM A312-316L (K) |
Metrode 20.25.4 / ER385 |
6G |
AS3992:1998, ASME IX:2004 |
| GTAW-03-03 |
Fillet |
ASTM A312-316L (K) |
ASTM A312-316L (K) |
Metrode 20.25.4 / ER385 |
6G |
AS3992:1998, ASME IX:2004 |
| GTAW-04-01 |
Fillet |
ASTM A312-316L (K) |
ASTM A312-316L (K) |
BOC Profill 316 / ER316L |
6G |
AS3992:1998, ASME IX:2004 |
| GTAW-04-02 |
Fillet |
ASTM A312-316L (K) |
ASTM A312-316L (K) |
BOC Profill 316 / ER316L |
2F |
AS3992:1998, ASME IX |
| GTAW-04-03 |
Fillet |
ASTM A312-316L (K) |
ASTM A312-316L (K) |
BOC Profill 316 / ER316L |
5F |
AS3992:1998, ASME IX |
| GTAW-09-01 |
Fillet |
ASTM A276-98B |
ASTM A276-98B |
ER2209 Sandvik 2209 |
2F |
AS1554-6 ASME IX |
Manual Metal Arc Welding
| Document WPS |
Joint |
Material 1 |
Material 2 |
Consumable's |
Pos |
Standard |
| MMAW-02-01 |
Fillet |
ASTM A312-304L (K) |
ASTM A312-304L (K) |
Metrode 21.26.5 / ER20.25.5 |
2F |
AS3992:1998, ASME IX:2004 |
| MMAW-02-02 |
Fillet |
ASTM A312-304L (K) |
ASTM A312-316L (K) |
Metrode 21.26.5 / ER20.25.5 |
2F |
AS3992:1998, ASME IX:2004 |
| MMAW-02-03 |
Fillet |
ASTM A312-316L (K) |
ASTM A312-316L (K) |
Metrode 21.26.5 / ER20.25.5 |
2F |
AS3992:1998, ASME IX:2004 |
| MMAW-02-04 |
Fillet |
UNS N08904 (K) |
UNS N08904 (K) |
Metrode 21.26.5 / ER20.25.5 |
2F |
AS3992:1998, ASME IX:2004 |
| MMAW-03-01 |
Butt |
ASTM A106B (A1) |
ASTM A106B (A1) |
Kobe LB52U / E7016 |
2G |
AS3992:1998, ASME IX:2004 |
| MMAW-03-02 |
Butt |
ASTM A106B (A1) |
ASTM A106B (A1) |
Kobe LB52U / E7016 |
3G |
AS3992:1998, ASME IX:2004 |
| MMAW-03-03 |
Butt |
ASTM A106B (A1) |
ASTM A106B (A1) |
Kobe LB52U / E7016 |
4G |
AS3992:1998, ASME IX:2004 |
| MMAW-03-04 |
Butt |
AS3678 GR250 (A1) |
AS3678 GR250 (A1) |
Kobe LB52U / E7016 |
2G |
AS3992:1998, ASME IX:2004 |
| MMAW-03-05 |
Butt |
AS3678 GR250 (A1) |
AS3678 GR250 (A1) |
Kobe LB52U / E7016 |
3G |
AS3992:1998, ASME IX:2004 |
| MMAW-03-06 |
Fillet |
ASTM A106B (A1) |
ASTM A106B (A1) |
Kobe LB52U / E7016 |
2F |
AS3992:1998, ASME IX |
| MMAW-03-07 |
Fillet |
ASTM A106B (A1) |
ASTM A106B (A1) |
Kobe LB52U / E7016 |
2F |
AS3992:1998, ASME IX |
| MMAW-03-08 |
Fillet |
ASTM A106B (A1) |
ASTM A106B (A1) |
Kobe LB52U / E7016 |
2F |
AS3992:1998, ASME IX |
| MMAW-06-01 |
Fillet |
ASTM A276-98B |
ASTM A276-98B |
E2209-17 Sandvik 22.9 3LR |
2F |
AS1554.6 ASME IX |
| MMAW-03-08 |
Fillet |
ASTM A106B (A1) |
ASTM A106B (A1) |
Kobe LB52U / E7016 |
2F |
AS3992:1998, ASME IX |
| MMAW-PR-01 |
Fillet |
AS3678 GR250 (A1) |
AS3678 GR250 (A1) |
Pipearc 6010P & Ferrocraft 61 |
3F |
AS1554:2000 |
| MMAW-PR-02 |
Butt |
AS3678 GR250 (A1) |
AS3678 GR250 (A1) |
Ferrocraft 11 & Ferrocraft 61 |
3G |
AS1554:2000 |
| MMAW-PR-03 |
Butt |
ASTM A106B (A1) |
ASTM A105 (A1) |
Ferrocraft 61 / E4818-3 |
6G |
AS1554:2000 |
| MMAW-PR-04 |
Fillet |
AS3678 GR250 (A1) |
AS3678 GR250 (A1) |
Kobe LB25U / E4816-3 |
2F |
AS1554:2000 |
| MMAW-PR-05 |
Fillet |
AS3678 GR250 (A1) |
AS3678 GR250 (A1) |
Kobe LB25U / E4816-3 |
4F |
AS1554:2000 |
